DIN rail:
TH35-15 (EN60715)
Rated dynamic current Idyn:
2.5Ith
Categorie produs:
Normal installation (EN60044-1)
Gama de temperatură - Funcţionare:
-25 la +50
PROMO CODE CH:
8013-0043-40
Max. Operating voltage Um:
0.72kV r.m.s.
Domeniul de frecvenţă:
47 - 63Hz
Short-time current Ith:
< 60Ipr
Reference temperature:
23°C ±1°C
Bare colectoare maxim:
60x10
Thermal rated continuous current according to EN60044-1:
##
Rated current primary side Ipr:
600
Metodă de montaj:
snap-on DIN rail 35 mm;screwable for wall mounting
Gama de temperatură - Transport/Depozitare:
-40 to +85
Notă:
Calibrated and listed by the Austrian Federal Office of Metrology and Verification (BEV) as a billing current transformer and can therefore be calibrated.;The transformers are not included in the MID directive, which means that the national BEV standard applies here.;If current transformers are used with energy meters for official billing purposes, only devices approved and calibrated in accordance with the calibration law should be used.
Daily average temperature:
≤ 30°C
Rated current secondary side Isr:
5A
Opţiuni:
trafo curent metrologizat
Intended use:
for copper bars up to 60 x 10mm
Descriere electrică CAD:
600/5A
Insulation requirements:
##
Housing material:
Polycarbonate, self-extinguishing;Class V0 according to UL-94
Specifications:
calibratable
Temperatura minimă a mediului ambiant:
-25
Temperatura maximă a mediului ambiant:
55
Accesorii opționale:
MGX20006--;MGX20306--;MGX20406--
Terminal labeling:
Winding primary side P1(K) - P2(L);Winding secondary side s1(k) - s2(l)
Isolation:
Class B (EN60044-1)
Isolation test voltage :
3 kV R.M.S. 50 Hz/1min
Versiune:
Dry type transformer, air insulation
